4 channel momentary remote wiring diagram. This little 4 channel wireless remote relay unit works out of the box in momentary mode. 4 channel infrared remote relays electronic circuit diagram circuit and wiring diagram download for automotive car motorcycle truck audio radio electronic devices home and house appliances published on 13 jun 2016. 4 channel latch or momentary on board jumper for selection. 4 channel rf remote built using pt2262 and pt2272 m4 ic from princeton technology.

Push the learning button on the receivers for 8 times the codes will be cleaned. 4 channel infrared ir remote controller is using ht12a and ht12d encoder decoder chips from holtek. The receiver provides 4 channel momentary outputs. Release the remote control button such as a and the corresponding relay on the receiver will turn off.

Transmitter works with 5v to 12v dc. 433mhz universal wireless remote control switch dc12v 10a 1ch relay receiver module and rf transmitter 433 mhz remote controls from. 5 vdc 200 ma. 4 channel switch receiver need 4 buttons remote control transmitter.

In the default configuration it only allows one button to be pressed at a time this was perfect for my application. After successful pairing in this mode press and hold the remote control button such as a the corresponding relay on the receiver is turned on. 39 12v rf wireless remote control switch 10a universal 4 channel 433mhz remote relay switch for led lamp lights motor diy function more 4 transmitters with 1 receiver 5 out of 5 stars 5. Remote control included control up to 4 different devices with a single controller and key fob remote.

The receiver unit has 4 channels each of which can be independently configured to momentary or latching mode via dip switch. Pt2262 used as encoder transmitter and pt2272 m4 decoder receiver ics are heart of the project. Crystal based oscillator for reliability of operation. All outputs are ttl level can be interface with other circuits or relay board.

Clearing the code. Jumper selectable 8 bit. Free shipping for many products.
